Wouxun KG-UV9D(Plus) Amateur Ham Two-Way Radio

Wouxun KG-UV9D(Plus) Amateur Ham Two-Way Radio

(2 customer reviews)

$199.99 $139.00

The Wouxun KG-UV9D(Plus) provides reliable EmComm emergency radio communications for amateurs/hams, SHTF preppers, survivalists, Neighborhood Watch, ARES, RACES & CERT groups to keep in touch when other methods of communication break down.

ReadySafeGo™ charged, tested & custom pre-programmed for SHTF* with 917 channels! – See PDF programming chart in description!

Custom Programming & Consulting Available!

Not sure what you need? Contact us and we’ll be happy to help!

Note: Current supply is limited. Place your Backorder now to get in line! (1-2 week est.)

Only 2 left in stock (can be backordered)

000

Wouxun KG-UV9D(Plus) Amateur Ham Two-Way Radio



Key Features

999 Channels • Programmable • VHF 5/2/1 Watts • UHF 4/2/1 Watts • Dual-Band • IP55 Jets Rated • Handheld • Analog FM • Part 15B FCC Certification • Part 97 Amateur/Ham • Wide 7-Band Receive Range • TDR (True Dual Receivers) • Built-In Cross-Band Repeater • Dual-PTT • Dual Scanning • 20 FM Broadcast Memories • Color Screen • Keypad • 3 Programmable Side-Keys • 2.5kHz Tuning Steps • Flashlight • 2 Antennas • Wrist Strap • Belt Clip • English Manual

Tx Range (MHz): 136-174 VHF • 400-512 UHF – Tx Locked to Ham
Rx Range (MHz): 76-108 FM Broadcast Radio • 108-136 AM AIR • 136-180 FM/AM VHF • 230-250 FM/AM VHF • 350-400 FM/AM UHF • 400-512 FM/AM UHF • 700-985 FM/AM UHF

ReadySafeGo™ charged, tested & custom pre-programmed for SHTF* with 917 channels! – Ships with Tx locked to Ham bands for Part 97 compliance. User programmable with free (downloadable) or advanced software kit.*

Custom Programming & Consulting Available! Not sure what you need? Contact us and we’ll be happy to help!



Description

The advanced Wouxun KG-UV9D(Plus) is a 999 channel programmable dual-band handheld analog FM Ham two-way radio transceiver with wide 7-band receive range, TDR (true dual receive), and built-in cross-band repeater, ideal for amateur radio, SHTF preppers, survivalists or EmComm emergency communications. It has 2.5kHz tuning steps and comes custom pre-programmed for SHTF* (ships with Tx locked to Ham bands only for Part 97 compliance). Programmable with free (downloadable) or advanced software kit.

With up to 5 Watts of power and a talk-around range of 1 to 6+ miles (many more when used with repeaters), the KG-UV9D(Plus) provides reliable emergency radio communications for amateurs, peppers, survivalists, Neighborhood Watch, ARES, RACES & CERT groups to keep in touch when other methods of communication break down. IP55 rated and Part 15B Certified & Part 97 compliant.

The KG-UV9D(Plus) operating range is as good or better than any other affordable Commercial/Ham radio, even with its two included stock flexible antennas, which are better than most radios in this price range. As well, with our hi-gain whip antenna upgrade, an emergency Ed Fong roll-up, external mobile-mount, or base station antenna, you will see a significantly improved talk range, even when communicating with another stock handheld. The KG-UV9D(Plus) is also repeater-capable (even split-band), greatly extending the potential operating range. In addition, the radio features a single or bi-directional cross-band repeater, turning the KG-UV9D(Plus) into a powerful portable communication device. With its True Dual Receive, the UV9D(Plus) is also great for AMSAT Amateur Satellite work.



Highlights

Ham Radio
Great for SHTF (S#it Hits The Fan) Survival preppers and Amateur Radio (Ham) communications, including CERT, ARES, RACES & SKYWARN. Full 5 Watts of transmit power on VHF and 4 Watts on UHF for maximum range. Note: We offer custom programming for this radio – see the Radio Programming Charts below!
True Dual Receive, Cross-Band Repeater & FM Radio
Allows monitoring two communication channels simultaneously (V+V, U+U & V+U) in TDR mode (can also set sub-receiver to mute when main receiver is active). Great for scanning emergency channels while monitoring a “home” channel, simultaneous scanning different bands or scan groups (ranges of channels) on both receivers at the same time, or even listening to FM Broadcast Radio. Single receive mode is also available.
999 Channels & 3 Power Levels
Easily program up to 999 regular VHF/UHF channel memories with 8-character alpha-numeric tags, and 20 FM Broadcast Radio station channels (1019 channels total). 3 programmable power levels for operating flexibility (VHF: 5/2/1W, UHF: 4/2/1W). There’s even a bright LED flashlight built-in – handy for emergencies.
Pro Features & 1 Year Warranty!
Easy to operate radio with its compact size, simple menu system and Front Panel Programming. Each radio includes a 2000 mAh Li-ion rechargeable battery (provides 18+ hours of operation between charges with battery-saver mode), 2-4 hour desk charger, 2 flexible antennas (dual-band 4″ & 8″ rubber duckies for short and longer range comms.), belt clip, wrist strap & user manual. Backed with impressive 1 year limited warranty (on radio, 6 months on battery and charger).

Note: Amateur Radio (Ham) operation requires an FCC license. This radio is not “type-accepted” for use on other bands such as GMRS, FRS, MURS, MMS, LMR, etc.

*IMPORTANT: This radio is meant for personal use by licensed amateur radio operators during normal or emergency “SHTF” (S#it Hits The Fan) situations. Although our radios come programmed for Part 97 compliance with transmit locked to only the Ham bands, you are ultimately and solely responsible for operating this device in compliance with FCC licensing and regulations, regardless of how it comes programmed. For EmComm use, consult your COML regarding device compliance before any official public service operation. The free downloadable custom programming software made available for this radio by the manufacturer is for use by service technicians authorized or licensed to reprogram the radios for any given radio service. We are not responsible for any harm or loss caused by the use or misuse of this device. Please let us know if you have any compliance questions before purchasing.



Features

Channels:999 Channels – 999 VHF/UHF + 20 FM Broadcast radio stations. Front Panel Programmable (with optional USB Programming Cable), Large backlit Color LCD Display with 8-character alpha-numeric channel names, simple menu system and quick-access function buttons. Note: PC programmable with optional USB cable and free or advanced software, or with our additional custom programming service – see the Custom Radio Programming item in the KG-UV9D(Plus) & 9P Accessories category.
Wide Receive:Extended Receive Range with FM Broadcast & AM AIR Band. Rx: 76-108MHz (FM Broadcast Radio), 108-136MHz (AM AIR), 136-180MHz (FM/AM VHF), 230-250MHz (FM/AM VHF), 350-400MHz (FM/AM UHF), 400-512MHz (FM/AM UHF), 700-986MHz (FM/AM UHF)
Battery:Operate 18+ hours between charges with the supplied 2000 mAh lithium-ion battery in the power saver mode. Power-on battery voltage display (and inside menu) to easily monitor battery life.
Applications:Ideal communications for hobbyists, survivalists & (amateur radio) Hams to keep in touch. Great for SHTF (S#it Hits The Fan) Preppers & general “EmComm” Emergency communications also!
Flashlight/VOX/FMIncludes a bright LED Flashlight feature, a hand-free VOX feature, and FM Broadcast Radio receiver – Great for monitoring a game or emergency broadcast. There’s also an SOS Alarm mode and dual-receive Scanning, with multiple scan resume modes, and DTMF Encoding. There’s also an optional Stopwatch function, Free Windows Programming Software, Busy Channel Lockout, Keypad Lock, Transmit Time Out, multiple Tuning Step Sizes (from 2.5 to 100 kHz), Power SaveBacklit Keypad and more!
Audio Output:500 mW of loud-speaker output for noisy environments. It’s surprisingly loud and clear for a radio of this size!
Quiet Tones/Codes:50 CTCSS & 105 DCS “PL” tones or digital codes with split capability. Quiet/privacy tones/codes are re-programmable with the optional USB Programming Cable or front panel keypad (when unlocked). Note: We can re-program the radio with standard/default PL tones – see the Radio Programming Charts below!
Special Features:3 Side-buttons (with custom programming options) as follows: Sub-Receiver Tx, Selective Calls, Scan Mode, Stopwatch, Flashlight, Keypad Light, Frequency Shift/Direction, SOS Alarm, FM Radio, Monitor. See the Radio Programming Charts below for all settings!
Package Includes:Commercial-Grade 999-Channel Dual-Band True-Dual-Receive radio (Operating Range: VHF 5/2/1W 136-174MHz, UHF 4/2/1W 400-512MHz, stock radio has transmit locked to ham bands – Tx: VHF 144-148 MHz, UHF: 420-450 MHz), lithium-ion batterydesk charger, 4″ dual-band & 8″ full-band flexible whip antennassturdy belt clip w/ screws, user manual & wrist strap.
Opt. Accessories:External Compact & Heavy Duty Speaker Mics, AA Alkaline Battery Case, Spare 2000 mAh Li-ion Battery Pack, 12V Cig. Lighter Battery Eliminator, 12V Car Charger Adapter, 18″ Magnetic Mount Dual-Band Vehicle Antenna, Hi-Gain 15″ Whip Antenna, 2.75″ Stubby Flexible Antenna, Ext. Covert Earpiece, Radio Cloning Cable, USB Radio Programming Cable, Replacement Desk Charger, Replacement Belt Clip, HD Nylon Carry Case (windowed) w/ Stainless Swivel Belt Clip.
Certifications:FCC Part 15B Certified (for Part 97 Amateur Radio use)
IP55 Dust & Water (jets) Resistant

Need Custom Programming or Consulting?

Utilize our BSR-PCON Custom Radio Programming & Consulting Service and we’ll handle any custom research & programming for you!

Programming Chart (Tx locked to Ham bands)

KG-UV9D(Plus)
917 Channels
S#it Hits The Fan – All Prepper VHF/UHF+View “SHTF” Custom Programming Chart

Custom Radio Programming Options

KG-UV9D(Plus)-CUSTCustom Radio Programming – Anything You Want!View KG-UV9D(Plus) Custom Programming Options (Coming Soon!)Download KG-UV9D(Plus) Custom Programming XLSX Template ZIP (Coming Soon!)

Custom Programming Software

KG-UV9D(Plus)Ham CPSKG-UV9D(Plus) Programmer
DriverWXUSB CP210x USB Cable DriverCP210x WXUSB USB Driver

Note: The programming software is provided by the manufacturer as a courtesy and is not guaranteed to be available or updated in the future.

IMPORTANT: By downloading and using this custom programming software, you agree to be solely responsible for operating your radios in compliance with FCC licensing and regulations. For use by service technicians authorized or licensed to reprogram the radios for any given radio service. We are not responsible for any harm caused by the use or misuse of this software to or by your radios. We do not offer free consulting or support for the free programming software, but we can program your radios for you or provide hourly-rate consulting instead! Let us know if you have any questions before purchasing.

Additional information

Weight1.6 lbs
Dimensions10.5 × 7.75 × 3.5 in
Channels

999 (Plus 20 FM Broadcast Radio), Programmable

Bands

Tx: Ham
Rx: Ham/MURS/GMRS/FRS/PLMRS/CAP/WX/PS/AIR/AAR & more!
Custom Programmable for other VHF/UHF bands

Receive Frequency Range

76-108MHz (Broadcast FM Radio)
108-136MHz (AM AIR)
136-180MHz (FM/AM VHF)
230-250MHz (FM/AM VHF)
350-400MHz (FM/AM UHF)
400-512MHz (FM/AM UHF)
700-986MHz (FM/AM UHF)

Transmit Frequency Range

144-148MHz (FM 2M Ham VHF), as shipped for Part 97 compliance
420-450MHz (FM 70cm Ham UHF), as shipped for Part 97 compliance
Custom Programmable*

Operating Modes

Single or True Dual Receive
VHF/VHF, VHF/UHF, UHF/UHF
(mutable sub-receiver)

CTCSS & DCS

155 CTCSS/DCS “PL/Privacy” tones or digital codes with split capability

Frequency Stability

±2.5PPM

Receive Sensitivity

108-136MHz(AM) -106dBM SINAD 13db
136-180MHz(AM) -119dBM SINAD 13db
230-250MHz(AM) -116dBM SINAD 13db
350-400MHz(AM) -119dBM SINAD 13db
400-512MHz(AM) -119dBM SINAD 13db
700-985MHz(AM) -96dBM SINAD 13db

Adjacent Channel Selectivity

≤70dB @ 25kHz
≤60dB @ 12.5kHz

Intermod Rejection

≤65dB @ 25kHz
≤60dB @ 12.5kHz

Spurious Response Rejection

≤70dB

S/N

≥45dB @ 25kHz
≥40dB @ 12.5kHz

Audio Power Output

≤500mW, Built-In Loudspeaker
≤5% Distortion

RF Power Output

VHF High Power: 5W / Mid Power: 2W / Low Power: 1W
UHF High Power: 4W / Mid Power: 2W / Low Power: 1W

Modulation/Bandwidth

FM (Frequency Modulation), ≤5% FM Distortion
WFM (Wide Band FM), 16kΦF3E, 25kHz
NFM (FM Narrow Band), 11kΦF3E, 12.5kHz
F2D (AM) Receive
Narrowband-Compliant with 2.5kHz Tuning Steps

Max Deviation

WFM ±5kHz
FMN ±2.5kHz

Tx Spurious & Harmonics

>60dB

Antenna Impedance

50Ω (both included antennas)

Battery Pack

2000mAh 7.4V Li-ion

Voltage

DC 7.4V via Li-ion Battery Pack, AA Battery Case or 12V Battery Eliminator

Radio Weight

Assembled Radio: 266g (9.4oz) with Stock 8" Antenna & Li-ion Battery Pack
Assembled Radio: 258g (9.1oz) with Stock 4" Antenna & Li-ion Battery Pack

Radio Dimensions (HxWxD)

124.5x62x34mm without Antenna

Operating Temperature

-30°C~+60°C
-22°F~+140°F

Dust & Water Protection

IP55 Dust & Water (jets) Resistant

FCC Certification

FCC Part 15B Certified device & Part 97 Amateur Radio (Ham) Compliant
Narrowband-Compliant with 2.5kHz Tuning Steps (but not Part 90 Cert.)
FCC ID: WVTWOUXUN12

Warranty

1 Year Manufacturer's Warranty on Radio
6 Months Manufacturer's Warranty on Battery & Charger
